introduction
ata-7015 is an ideal single-channel high voltage amplifier that can amplify the ac and dc signals. maximum output voltage 3kvp-p (±1.5kvp); output peak current 40map, matching with the mainstream signal generator, realize perfect signal amplification.
input
the input is bnc interface, the input resistance is 10kω.
output
the output interface is shv rf connector, maximum output voltage 3kvp-p (±1.5kvp), maximum output current is 40map.
lcd displays
ata-7015 is provided with lcd to display the equipment state and parameters dynamically, the operation interface is clear at a glance, concise and easy to understand.
voltage gain
the voltage gain can be adjusted by 0 ~ 1000 times. combined with the lcd panel gain display, it can quickly adjust to the required voltage value.
monitor
1/1000 monitor: the port voltage is 1/1000 of output port, the monitoring port is bnc connector that can be connected with the oscilloscope for monitoring the output voltage in real time.
